Durable Heavy Load Construction Site Loading Platform For Efficient Material Flow

Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | Steel | Safety | High |
---|---|---|---|
Weight | Heavy | Surface Treatment | Painted, Hot Galvanized |
Installation | Easy | Durability | Long Lasting |
Load Capacity | High | Size | Customizable |
Highlight | Galvanized Construction Site Loading Platform,Retractable Loading Platform,Galvanized Steel Mobile Loading Platforms |
Durable And Heavy Load Construction Site Loading Platform For Efficient Material Flow
Product Description:
Loading Platform is a customizable, heavy-duty product made of steel, which ensures a high level of safety and easy maintenance. It is suitable for a wide range of applications, from the construction of floors and multi-storey buildings to loading and unloading operations. The highly durable steel construction offers superior strength and stability, and the customizable design allows you to tailor the product to your exact needs. With its superior strength and stability, Loading Platform is the perfect choice for any construction project.
Features:
- Product Name: Loading Platform
- Material: Steel
- Installation: Easy
- Maintenance: Easy
- Surface Treatment: Painted, Hot Galvanized
- Durability: Long Lasting
- Ideal for Construction Site: Yes
- Retractable Loading Deck: Yes
- Multi Storey Building Construction: Yes
Technical Parameters:
Property | Details |
---|---|
Name | Retractable Loading Deck, Movable Loading Platform |
Surface Treatment | Painted, Hot Galvanized |
Load Capacity | High |
Size | Customizable |
Durability | Long Lasting |
Material | Steel |
Safety | High |
Color | Customizable |
Maintenance | Easy |
Weight | Heavy |
Model SXP250 Retractable Loading Deck
Item | Unit | Data | Note |
Outer Width | mm | 2410 | Customizable |
Inner Width | mm | 1680 | |
Forth/Rear Support Prop Spacing | mm | 1600 | |
Left/Right Support Prop Spacing | mm | 2000 | |
Min Support Prop Height | mm | 2200 | |
Max Support Prop Height | mm | 4500 | |
Length at Retracted State | mm | 3600 | |
Length at Extended State | mm | 5370 | |
Extending Out Length of Stationary Frame | mm | 1130 | |
Distance from Front Prop to Building Facade | mm | 652 | |
Extending Length of Moveable Deck | mm | 1870 | |
Overhang Distance | mm | 3000 | |
Maximum Total Load (equidistribution) | ton | 2.5 |
Applications:
The Loading Platform is a movable, retractable platform that allows users to safely and easily load and unload items from trucks, ships, and other vehicles. It is made of high quality materials, ensuring a high load capacity and long lifetime. The platform is customizable, allowing you to choose any color for your needs. It is also easy to maintain, making it an ideal choice for loading operations. This product is made in China and payment terms such as T/T and LC are accepted before shipment. It provides a safe and efficient way to transport goods from one place to another. The Loading Platform is an excellent choice for commercial businesses, warehouses, and factories.
Support and Services:
At Loading Platform, we are dedicated to providing our customers with the best technical support and service possible. We want to make sure that you have the tools and information you need to make the most out of our products.
Technical Support
Our Technical Support team is available to help you with any questions you may have regarding the use of our products. We are available 24 hours a day, 7 days a week to answer your questions, troubleshoot any issues, and provide you with helpful resources.
Software Updates
We are constantly working to improve our products and we make sure to provide our customers with the latest software updates. Our software updates include bug fixes, security patches, new features, and performance enhancements.
Documentation
To help our customers get the most out of our products, we provide detailed documentation on how to use our products. Our documentation includes step-by-step instructions, screenshots, and helpful tips.
Online Forum
We have an online forum where customers can ask questions, get help from other users, and share tips and tricks. Our online forum is a great resource for our customers to get the most out of our products.
FAQ:
Q1: Where is loading platform produced?
A: Loading platform is produced in China.
Q2: What payment terms do you accept?
A: We accept T/T and LC before shipment.
Q3: What is the loading capacity of the platform?
A: The loading capacity of the platform varies according to the size and model, 2.5 - 5 tons is the most popular.
Q4: Is the platform easy to setup?
A: Yes, the platform is easy to setup and requires minimal effort.
Q5: How long does it take to deliver the platform?
A: Delivery time depends on the location of the delivery, typically it takes about 20-25 days.
