FC Motor Control Material Rack And Pinion Hoist Equipment
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200(BZ) KP-B07, B08 |
| Minimum Order Quantity | 1 unit |
| Price | Negocitate |
| Packaging Details | export package |
| Delivery Time | 30 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 150 set per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Material Hoisting Equipment | Applying Location | Construction Site, Plants, Etc. |
|---|---|---|---|
| Material | Q345B Cool Roll Steel Plate | Processing Procedure | Cut By Laser, Processed By CNC Machines In Tool Fixtures. |
| Finishing | Paint, Galvanised | Control | FC Motor Control |
| Highlight | rack and pinion material hoist,2000kg material hoist |
||
Product Description
FC Motor Control Construction Projects Material Hoisting Equipment
Material Hoisting Equipment Features
1. The technology from foreign advanced technology, excellent quality with stable and reliable performance.
2. Zero accident record
3. The products are processed by large-scale equipment, which is not only reliable in quality but also very beautiful in appearance
4. According to customer requirement to make OEM
5. Lifting speed can do low speed, Medium speed, and high speed.
6. more than 20 years experience.
Material Hoisting Equipment Standard Configuration
There is a electrical small crane available to facilitate the assembly of columns and doors on the floors.
Available in single or twin hoist cage configuration.
Frequency control makes the construction hoists starting and stopping very smoothly, with low starting current and much less wear and tear.
Manual or Automatic Controls of the hoist is optional.
Lighting inside construction elevator car is LED ceiling lamp
Material Hoisting Equipment Parameters
| Technical Data | KP-B07, B08 |
| Payload Capacity | 2000 kg |
| Lifting Speed | 0–46 m/min. |
| Max. Lifting Height | 450 m |
| Cage Width (internal) | 1.5 m |
| Cage Length (internal) | 3.2 m |
| Cage Height (internal) | 2.35 m |
| Motor Control | FC control |
| Engine Power | 2x15 kw |
| Gearbox | Helical Reducer |
| Safety Device | Centrifugal Brake |
| Power Supply Range | 380–500 V, 50 or 60 Hz, 3 phase |
| Mast Section | Square column 650*650*1508 mm with bolted rack |
| Rack Module | 8 |
