Construction Sites 2000KG Per Cage Rack And Pinion Hoist
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200BG KP-B11, SC200/200BG KP-B12 |
| Minimum Order Quantity | Negotiable |
| Price | Negotiable |
| Packaging Details | Export package |
| Delivery Time | 30 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 150 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Rack And Pinion Hoist | Application | Construction Sites |
|---|---|---|---|
| Design | According To European Regulation EN 12159:2012, EN 60204-1:2006/A1:2009. | Material | Q345B Cool Roll Steel Plate |
| Load | 2,000KG Per Cage | Finishing | Sandblasting And Painted, Galvanised |
| Highlight | Construction Sites rack & pinion hoist,2000kg Construction Sites Hoist |
||
Product Description
Construction Sites 2,000KG Per Cage Rack And Pinion Hoist
Rack And Pinion Hoist Introduction
1. Smooth, strating and braking cause no impact.
2. Lifting speed can be controlled.
3. The starting current is less than the rated current.
4. Mechanical wear is reduced. Thanks to zero impact in start-up, it greatly reduces the mechical wear of gears and racks and the brake wear is obviiously reduced.
5. It has significant energy saving effects.
Rack And Pinion Hoist Configuration
There is a electrical small crane available to facilitate the assembly of columns and doors on the floors.
Available in single or twin hoist cage configuration.
The construction rack and pinion elevators are Variable Frequency Drive (VFD), with low starting current and much less wear and tear, very smooth starting and stopping.
Manual or Automatic Controls of the hoist is optional.
Lighting inside construction elevator car is LED ceiling lamp
The construction material hoist cage roof doors are equipped with Interlock.
Equipped with hoist drop test facility with remote control.
Rack And Pinion Hoist Parameters
| Item & Article No. | SC200BG, KP-B11; SC200/200BG, KP-B12 Rack And Pinion Hoist |
| Payload Capacity | 2,000KG per Cage |
| Lifting Speed | 0–60 meter/minute. |
| Max. Lifting Height | 450 m |
| Cage Size (internal) | 3.2(Length)*1.5((Width)*2.35(Height) meter |
| Motor Power | 3x15 KW per Cage |
| Motor Control | Frequency Control (FC) |
| Invertor Power (KW) | 1*55KW per Cage |
| Gearbox | PIELI Helical Gearbox |
| Anti-drop Safety Device | Centrifugal Brake |
| Power Supply Range | 380–500 V, 50 or 60 Hz, 3 Phase |
| Mast Section | Square Column 650*650*1508 mm with Bolted Rack |
| Rack module | 8 |
