Rack And Pinion Elevator With Variable Frequency Drive Of Various Speed
| Place of Origin | Xiamen, China |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200 |
| Minimum Order Quantity | 1 unit |
| Price | Negocite |
| Packaging Details | Shipped in container |
| Delivery Time | 25 days after down payment |
| Payment Terms | L/C, T/T |
| Supply Ability | 300 units per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Veritical Transportation At Building Site | Standard | EU Regulations |
|---|---|---|---|
| Material | Q355B Steel | Process | By CNC Machines And Robots |
| Finishing | Sand Blasting And Paint, Galvanised | Drive Type | Rack And Pinion |
| Mast | Square Column With Rack Bolted | Color | Yellow |
| Highlight | Variable Frequency Drive Rack Pinion Elevator,Building Site Rack Pinion Elevator,Variable Frequency Drive Rack Pinion Lift |
||
Product Description
Rack And Pinion Elevator With Variable Frequency Drive Of various Speed
Twin Cabin /Single cabin Material & Passenger Construction Hoist
1. Description
Construction hoist is referred to building construction elevator, outdoor elevator, builders hoist. It is widely used as construction machinery to transport people and building materials.
Construction hoist is mainly used for the jobs of internal and external decoration, bridge building, chimney, etc
SC series Construction Hoist/Elevators adopts rack-and-pinion transmission. For years of improvement, it has become newly designed, compact structure, convenient operation, easy installation and disassembly, beautiful shape and reliable performance.
> Mast Section Dimension: 650 * 650 * 1508mm, 800 * 800 * 1508mm
> Main Chord: Φ76 * 4.75, Φ76 * 6.0, Q355B steel
Structure forms varies: SC two drives, SC three drives without counterweight, built-in upper-setting and frequency control, etc.
Application: the equipment is applicable to people and material transporting in high building construction that above 60m, such as bridges, chimneys, mansions, etc.. And can also be used in warehouse , wharf, etc for vertical transportation
Space dimension of cage 3.2*1.5*2.5m
2. Main Technical Parameters SC series products
| Characteristic | Model | Rated Loading | Lifting Speed | Motor Power | Inverter Power |
| Twin Cage | SC150/150 | 2×1500kg | 0-54m/min | 2×11 Kw | 30 Kw |
| SC200/200 | 2×2000kg | 0-36m/min | 2×11 Kw | 30 Kw | |
| SC200/200 | 2×2000kg | 0-46m/min | 2×15 Kw | 37 Kw | |
| SC200/200 | 2×2000kg | 0-63m/min | 3×15 Kw | 55 Kw | |
| SC200/200 | 2×2000kg | 0-96m/min | 3×18.5 Kw | 75 Kw | |
| SC320(BZ) | 2x3200kg | 0-46m/min | 3x15 Kw | 55 Kw | |
| Single Cage | SC150 | 1500Kg | 0-34m/min | 2×9Kw | 22Kw |
| SC200 | 2000kg | 0-45m/min | 3×12Kw | 37 Kw | |
| SC200 | 2000kg | 0-34m/min | 2×12Kw | 37 Kw | |
| SC200 | 2000kg | 0-63m/min | 3×15 Kw | 45 Kw | |
| SC200 | 2000kg | 0-96m/min | 3×18.5 Kw | 75 Kw | |
| SC320(BZ) | 3200kg | 0-46m/min | 3x15 Kw | 55 Kw |
3. Features
Mast section welded by welding Robot ensures reliable quality and elegant appearance.
All the steel structures are processed with blasting technology to remove rust. The adhesion of surface painting is outstanding.
Cage guarding board adopts figured steel plate and numerical control punched steel plate. The cabin is lightweight and artistic in appearance.
Transmission mechanism supplied by the professional manufacturer has high efficiency, long service life and stability in performance.
Complete set of overload protection devices, variety of limiters and mechanical chain devices ensure its reliability. Anti-falling safety device adopts centrifugal brake, which restricts the excessive downward movement of the cage, preventing and eliminating accidents.
Frequency conversional construction elevator is safe, stable and comfortable. Starting electricity is smaller than working electricity, energy-saving and high efficient.
