VFC Motor Control Construction Site Lift Yellow Color Max Lifting Height 400M
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200, KP-B05,B06 |
| Minimum Order Quantity | 1 Unit |
| Price | Negotiate |
| Packaging Details | Export package |
| Delivery Time | 30 days afetr receipt of T/T or L/C |
| Payment Terms | L/C, T/T |
| Supply Ability | 150 units per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Q345B Steel | Processing | Cut By Laser, Processed By CNC Machines |
|---|---|---|---|
| Apply Location | Construction Site, Plants, Etc. | Purpose | Vertical Transportation Of Materials And Persons |
| Color | Yellow | Name | Construction Site Lift |
| Highlight | building site lift,rack pinion hoist |
||
Product Description
Construction Hoists and Elevators Rack and Pinion Type SC200/200, KP-B05,B06
Product Features
Adopt own-make high efficient gear type reducers.
Typesof exit doors are availble, including Flap Door as loading/unloading ramp.
Production
Main parts are made of Q346 cool roll steel plate, cut by Laser and processed by CNC machines and robots.
Enlarged and thickened main steel channel of the cage frame.
The fully welded cage roof edges make the cage roof waterproof.
| Technical Data | KP-B05, KP-B06 |
| Payload capacity | 2,000 kg |
| Lifting speed | 0–36 m/min. |
| Max. lifting height | 400 m |
| Cage width (internal) | 1.5 m |
| Cage length (internal) | 3.2 m |
| Cage height (internal) | 2.35 m |
| Motor control | VFC control |
| Engine power | 2x11 kw |
| Gearbox | Gear Type Reducer |
| Safety device type | Centrifugal Brake |
| Power supply range | 380–500 V, 50 or 60 Hz, 3 phase |
| Type of mast | square column 650*650 mm with bolted rack |
| Length mast section | 1.508 m |
| Rack module | 8 |
