Interchangeable 2000 Kg Rack Pinion Lift Construction Hoist Elevator
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200(BD) KP-B07, KP-B08 |
| Minimum Order Quantity | 1 unit |
| Price | negotiate |
| Packaging Details | Export package |
| Delivery Time | 30 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 150 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Item | Construction Hoist Elevator | Design | Modular Design |
|---|---|---|---|
| Material | Q345B Cool Roll Steel Plate | Production | Processed By CNC Machines, Laser, Robots In Assembly Line. |
| Feature | Interchangeable | Load | 2,000 Kg |
| Highlight | 2000 Kg Construction Hoist Elevator,Rack Pinion Construction Hoist |
||
Product Description
Interchangeable 2,000 Kg Construction Hoist Elevator
Construction Hoist Elevator Design
It is the truly modular rack and pinion hoist design, so the construction elevator drive devices and cars are generic and interchangeable.
Construction Hoist Elevator Production and Materials
KANGBO implements the true modular design of construction rack and pinion hoists, standardization and fine finishing of lifts parts and spare parts, and assembly line production. The material elevator components are versatile and universal.
Construction Hoist Elevator Features and Advantages
* The Construction Site Lift runs without vibration or trembling. The man and material lift starts and stops without surging or jerking.
* The passenger and material elevator is reliable with very little breakdown and is durable with very long work-life.
* Adopt energy-saving helical reducers made specially for rack and pinion elevators, extremely strong, reliable and durable.
* Racks centering at mast reduce partial load torque of builders hoists, makes the construction hoists run more stably and smoothly.
* Applying non-eccentric rollers, make the installation of construction site elevators be faster and easier, with much less error.
Construction Hoist Elevator Parameters
| Technical Data | SC200/200BZ KP-B0708 Construction Hoist Elevator |
| Payload Capacity | 2,000 kg |
| Lifting Speed | 0–46 m/min. |
| Max. Lifting Height | 450 m |
| Cage Width (internal) | 1.5 m |
| Cage Length (internal) | 3.2 m |
| Cage Height (internal) | 2.35 m |
| Motor Control | Frequency Control |
| Engine Power | 2x15 kw |
| Gearbox | Helical Gearbox of KANGBO Make |
| Safety Device | Centrifugal Brake |
| Power Supply Range | 380–500 V, 50 or 60 Hz, 3 phase |
| Mast Section | Square column 650*650*1508 mm with bolted rack |
| Rack Module | 8 |
| * Increased lifting height on request. 250 m with step-up transformer only. 400 m with step-up/step-down transformer. | |
