Rack And Pinion Driven VFD Vertical Transporting Equipment 50M/Min
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | Construction Site Hoist Rack Pinion Type VFD Single Cage SC100(BZ) KP-B01 |
| Minimum Order Quantity | 1 set |
| Price | In negotiate |
| Packaging Details | A 40'HQ container can load one set of 60 meter high hoist |
| Delivery Time | 25 days after receipt of down payment |
| Payment Terms | T/T, L/C |
| Supply Ability | 300 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Description | Construction Site Hoist Rack Pinion Type VFD Single Cage SC100(BZ) KP-B01 | Application | Construction Site, Building Site, Bridges, Chimney, Plants, Etc |
|---|---|---|---|
| Design | According To European Standard And Truly Modular | Production | Standardized Production, Processed By CNC Machines, Laser, Robots In Assembly Line. |
| Material | Q345B Steel | Finishing | Sandblasting And Painted, Galvanised |
| Highlight | Transporting Equipment 50M/Min,VFD Vertical Transporting Equipment,Rack And Pinion Driven Construction Hoist |
||
Product Description
Efficient And Safety Vertical Transporting Equipment Construction Hoist
Technical Parameters:
| Technical Feature | Unit | Parameter |
| Rated Loading Capacity | kg | 1000*2 |
| Basic Height | m | 6 |
| Maximum Height | m | 450 |
| Cage size(Long*Wide*Height) | m | 3.2*1.5*2.5 |
| Lifting Speed | m/min | ≤50 |
| Motor Power | kw | 15*2 |
| Standard Section | m | 0.65*0.65*1.508 |
product description
SC series construction hoist is driven by rack and pinion, used on construction site for transportation of personnel and materials. Hoist function degree is A8. It is installed and dismounted conveniently and can grow as high as the building grow in height. This hoist has reliable electrical and mechanical safety device. It's efficient and safety vertical transporting equipment.
Features
1. All Production Line adopt special fixture, mould, gauge made by us to ensure all detailed size.
2. Select high quality raw material from China Bao Steel Group, other like motors ,reducers, gearbox, safety device with low noise, electrics is schneider or Korea repute brand with reliable quality
3. Special design,compact and reasonable structure,easy to installation and adjustment.
4. Each equipment should be test and make record in Factory, all details will be adjust like motor brake, safety device operation, all limit switch operation, dropping test, loading test, and mast section erection test to ensure the completed equipment run well when take into use.
