2000kg Video Technical Support Construction Site Hoist 200m
| Place of Origin | Xiamen, China |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200 |
| Minimum Order Quantity | 1 unit |
| Packaging Details | Shipped in container |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Max Lifting Height | 450m | Condition | New |
|---|---|---|---|
| Loder Weight | 2000kg | Rated Loading Capacity(kg) | 2*3200kg |
| Hoisting Speed | 0-46m/min | After-sales Service Provided | Video Technical Support |
| Color | Yellow | Cage | Double |
| Highlight | Double Cage Construction Site Hoist,2000kg Load Construction Site Hoist,Double Cage Construction Site Elevator |
||
Product Description
2000kg Video Technical Support Construction Site Hoist 200m
Product Description
1. Construction hoist could be designed according to different building situations.
2. With ISO9001,TUV, CE, certifications
3. Double or Single cage with loading capacity from1000kg to 3.200kg.
4. With Frequency converter or DOL control system with low speed, MID speed, and high speed.
5. All Production Line adopt special fixtures, mold, CNC machine tools made by us to ensure all sizes suitably.
6. Select high-quality raw material from China Bao Steel Group. The spare parts of motors, reducers, gearbox, safety device with low noise, while electrics parts of Schneider brand have reliable quality.
7. The compact and reasonable structure with the special design is easy for installation, adjustment and maintenance.
8. Each unit of equipment will be tested and made records in Factory and all details will be adjusted such as motor brake, safety device operation, all limit switch operation, dropping test, loading test, and mast section.
9. The erection test will ensure the completed equipment runs well when taken into use.
Product Info
| Item | Construction hoist |
| Model | SC320/320 |
| Rated capacity/per cage | 3200kg |
| Lifting speed | 0-46m/min |
| Cage size | 3.2*1.5*2.35m |
| Motor power | 3*15kw |
| Speed ratio | 1:16 |
| Invertor Power | 55 kw |
| Safety device | SAJ60-1.2 |
| Mast section size | 0.65*0.65*1.508m |
| Max. Installation height | 250m |
| Cable type | Cable Drum / Busbar |
3.2T 0-46/min Double Cages Energy Saving Construction Elevator
Construction elevator is a vertical transporting lifting tool for building construction, such as bradge. It is safe and efficient to lift materials and passenger to different floors. Loading Capacity range is 1000kg-3200kg.
1508*60*40 Rack and M8 pinion was applied to help the construction hoist climb the mast stably and efficiently and sefely.
Multi-equipment for safety: Safety device, up & down limit switch, Door limit switch, overload protector.
Wireless calling system for users.
Separate operator cabinet with comfortable space for operator. Also can make choose without operater cabinet.
Soft start and stop, with the help of advance VFD control.
WHY CHOOSE US?
KANGBO Machinery Group is a professional manufacturer and exporter that has been in this field for more than 20 years.
Our products are construction hoist. We can design special items according to building site circumtance and condition for the users.
1. 20 years more manufacturing experience and experiences.
2. Great technician Team with innovation and improvement abilities
3. Zero accident record and good feedback from the end-users.
4. High quality, and stable operation experience.
5. Fast response with sales and after-sale service
6. Welcome agents or distributors all over the world for cooperation partnership.
