Q355B Steel Sandblasting And Painted , Galvanised Construction Site Hoist
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | Construction Site Hoist Rack Pinion Type VFD Single Cage SC100(BZ) KP-B01 |
| Minimum Order Quantity | 1 set |
| Price | In negotiate |
| Packaging Details | A 40'HQ container can load one set of 60 meter high hoist |
| Delivery Time | 25 days after receipt of down payment |
| Payment Terms | T/T, L/C |
| Supply Ability | 300 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Description | Construction Site Hoist Rack Pinion Type VFD Single Cage SC100(BZ) KP-B01 | Application | Construction Site, Building Site, Bridges, Chimney, Plants, Etc |
|---|---|---|---|
| Design | According To European Standard And Truly Modular | Production | Standardized Production, Processed By CNC Machines, Laser, Robots In Assembly Line. |
| Material | Q355B Steel | Finishing | Sandblasting And Painted, Galvanised |
| Lifting Speed | 0-36m/min | Color | Yellow |
| Highlight | Q355B Steel Galvanised Construction Site Hoist,TUV Painted Construction Site Hoist,36m/min Building Site Hoist |
||
Product Description
Q355B steel Sandblasting and Painted , Galvanised Construction Site Hoist
Products Description
Salient Features of Construction Elevator
Mast section welded by welding Robot ensures reliable quality and elegant appearance.
All the steel structures are processed with blasting technology to remove rust. The adhesion of surface painting is outstanding.
Hoist cabin guarding board adopts figured galvanised steel plate and laser cutted plate. The cabin is lightweight and artistic in appearance.
Transmission mechanism own made patented gearbox has high efficiency, long service life and stability in performance.
Complete set of overload protection devices, variety of limiters and mechanical chain devices ensure its reliability. Anti-falling safety device adopts SAJ40-1.2, which restricts the excessive downward movement of the cage, preventing and eliminating accidents.
Frequency conversional construction elevator is safe, stable and comfortable. Starting electricity is smaller than working electricity, energy-saving and high efficient .
Product Info
| Parameter | Unit | Model | |||
| SC100 | SC100/100 | SC200 | SC200/200 | ||
| Rated capacity | kg | 1000 | 2×1000 | 2000 | 2×2000 |
| Number of people | No. | 12 | 2×12 | 18 | 2×18 |
| Rated lifting speed | m/min | 54 | 54 | 46 | 46 |
| Max.lifting height | m | 450 | 450 | 450 | 450 |
| Motor power | kw | 2×15 | 2×2×15 | 2×15 | 2×2×15 |
| Inverter | kw | 1×37 | 2×37 | 1×37 | 2×37 |
| Internal cage size | m | 3.2×1.5×2.35 | 3.2×1.5×2.35 | 3.2×1.5×2.35 | 3.2×1.5×2.35 |
| Weight of mast section | kg | 124 | 148 | 124 | 148 |
| Dimension of mast section | mm | 650×650×1508 | 650×650×1508 | 650×650×1508 | 650×650×1508 |
| Counter weight | kg | without | without | without | without |
| Internal cage size | m | 3.2×1.5×2.35 | 3.2×1.5×2.35 | 3.2×1.5×2.35 | 3.2×1.5×2.35 |
Product details
1. Guide rail system The building equipments is equipped with the guide rail system made of 20# steel that is 4.75mm thick.
2. The gear rack is made of LG60 steel and its service life is about 10 years.
3. Power system Same as the engine of a car, the elevating conveyor is the core part of an elevator. The housing is made of 104# GB aluminum to avoid any cracking. The 94# tin bronze is used to produce the worm gear. Other parts like the worm and fluted disc are made of 38# chrome green aluminum. Except the bronze worm gear, all other parts aforementioned should experience heat treatment, blackening and nitride coating. The work life time of the construction hoist is more than 15 years.
FAQ
1. Q: Are you factory?
A: Yes, we are a factory that located in XIAMEN for more than 20 years
2. Q: what is the delivery time?
A: It is according to the machine you need.
Q: How is the machine packed?
A: Each packed in carton, then put in wooden case, and then in container.
- Q: Why choose us?
A: We own high-quality, reasonable price. If purchase now,
we will supply you one set assembly auxiliary tools and one set wearing parts.
- Q: Can we visiting your factory?
A: We warmly welcome your visiting!
