VFD Motor Control Construction Site Elevator Cage Size Internal 3.2L * 1.5W * 2.35H Meter
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200(BD) |
| Minimum Order Quantity | 1 Unit |
| Price | Negotiate |
| Packaging Details | Suitable for export |
| Delivery Time | 30 day |
| Payment Terms | L/C, T/T |
| Supply Ability | 150 units per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Q345B Cool Roll Steel Plate | Color | Yellow |
|---|---|---|---|
| Inverter Brand | Schneider | Gearbox | Helical Gearbox |
| Finishing | Painted And Galvanised | ||
| Highlight | rack and pinion lifter,construction man lift |
||
Product Description
VFD Rack and Pinion Construction Site Elevator SC200(BD) KP-B05,B06
Features
Truly modular design and standardized production.
Variable Frequency Control motors make the elevator start/stop smoothly.
Production
Elevator parts are made of Q346 cool roll steel plate, processed by Laser and CNC machines in tool fixtures.
Full set of safety facilities, including centrifugal brake, limit switches, emergency limit switches, electromechanical interlock.
Process and Production
Main parts are made of Q345 steel and processed by CNC machines and robots.
Strengthened cage frames of which steel channel are enlarged and thickened.
| Technical Data | KP-B05, KP-B06 |
| Max. Lifting Height | 400 m |
| Payload | 2,000 kg |
| Lifting Speed | 0–36 m/min. |
| Cage Size (internal) | 3.2(L)x1.5(W)*2.35(H) meter |
| Motor Control | VFD control |
| Motor Power | 2x11 kw |
| Gearbox | KANGBO make Helical reducer |
| Safety Device Type | centrifugal brake |
| Type of Mast | square column 650*650 mm with bolted rack |
| Length Mast Section | 1.508 m |
| Rack Module | 8 |
