VFC Motor Control 450m Rack & Pinion Building Construction Lift
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | Construction hoist elevator SC200BG KP-B11 SC200-200BG KP-B12 |
| Minimum Order Quantity | 1 set |
| Price | In USD |
| Delivery Time | 25-30 Days |
| Payment Terms | T/T, L/C |
| Supply Ability | 150 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Description | Building Construction Lift | Design | According To European Regulation |
|---|---|---|---|
| Material | Q345B Cool Roll Steel Plate | Production | Standardized Production, Processed By CNC Machines, Laser, Robots In Assembly Line. |
| Motor Control | VFC Motor Control | Finishing | Sandblasting And Painted, Galvanised |
| Highlight | 450m Construction Lift,Rack & Pinion Building Lift |
||
Product Description
VFC Motor Control 450m Building Construction Lift
Building Construction Lift Introduction
Due to the frequency conversion elevator using computeraided design,configuration of frequency conversion device, so compared with the traditional construction lifter, smooth starting and stopping, effectively reduce the wastage of the parts, prolong service life, it has a high transmission efficiency, beautiful shape, light structure, tear open outfit is convenient,safe and reliable, strong applicability, wide range of USES, etc.
Building Construction Lift Features and Advantages
* The modular and standardizing system makes the Kangbo construction elevators be flexible, efficient, safe, productive, low energy consumptive and ownership cost, making them the best choice for both construction and rental companies.
* The material hoist runs without vibration or trembling. The man and material lift starts and stops without surging or jerking.
* The passenger and elevator is reliable with very little breakdown and is durable with very long work-life.
* Adopt energy-saving helical reducers made specially for rack and pinion elevators, extremely strong, reliable and durable.
* Racks centering at mast reduce partial load torque of builders hoists, makes the construction hoists run more stably and smoothly.
* Applying non-eccentric rollers, make the installation of construction site elevators be faster and easier, with much less error.
* The integrated elevator car roof, which made by a steel plate with edges fully welded one time to complete, enhance hoist cage strength and ensure no water leakage.
* Easy access to electrical panels of elevator for maintenance
* Certified safety braking system of rack and pinion hoist.
* The material elevator car frame is enlarged and strengthened.
Certificate
TUV proved according to European Regulation EN 12159:2012, EN 60204-1:2006/A1:2009.
Building Construction Lift Technical Data
| Item & Article No. | SC200BG, KP-B11; SC200/200BG, KP-B12 Building Construction Lift |
| Payload Capacity | 2,000KG per Cage |
| Lifting Speed | 0–60 meter/minute. |
| Max. Lifting Height | 450 m |
| Cage Size (internal) | 3.2(Length)*1.5((Width)*2.35(Height) meter |
| Motor Power | 3x15 KW per Cage |
| Motor Control | Frequency Control (FC) |
| Invertor Power (KW) | 1*55KW per Cage |
| Gearbox | PIELI Helical Gearbox |
| Anti-drop Safety Device | Centrifugal Brake |
| Power Supply Range | 380–500 V, 50 or 60 Hz, 3 Phase |
| Mast Section | Square Column 650*650*1508 mm with Bolted Rack |
| Rack module | 8 |
