VFD Motor Control 36 M / Min Material Rack And Pinion Elevator
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200(BD) |
| Minimum Order Quantity | 1 Unit |
| Price | Negotiate |
| Packaging Details | Suitable for export |
| Delivery Time | 30 day |
| Payment Terms | L/C, T/T |
| Supply Ability | 150 units per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Rack And Pinion Elevator | Control | VFD Motor Control |
|---|---|---|---|
| Inverter Brand | Schneider | Gearbox | Helical Gearbox |
| Finishing | Painted And Galvanised | Speed | 0–36 M/Min |
| Highlight | 36 M / Min Material Elevator,vfd rack pinion lift |
||
Product Description
VFD Motor Control 0–36 M/Min. Rack And Pinion Elevator
Rack And Pinion Elevator Feature
1. The Construction lift is equipped with a state-patented safety device which can brake automatically in case of accidental fall.
2. Comparing with traditional building hoists, it is attractive, light and is easy to handle, secure, applicable.
3. Construction passenger hoist is excellent in technical performance, more secure in operating mechanism, and more compact in structure.
4. The driver element on top of the cage is safe and reliable and convenient for maintenance.
5. It has simple electrical control system, convenient to be maintained and low failure rate;
6. With the advantages of reliable performance, safety, easy carrying, high adaptability, it can reduce operators’ work intensity.
Rack And Pinion Elevator Production
Elevator parts are made of Q346 cool roll steel plate, processed by Laser and CNC machines in tool fixtures.
Full set of safety facilities, including centrifugal brake, limit switches, emergency limit switches, electromechanical interlock.
Rack And Pinion Elevator Process and Production
Main parts are made of Q345 steel and processed by CNC machines and robots.
Strengthened cage frames of which steel channel are enlarged and thickened.
Rack And Pinion Elevator Paraeters
| Technical Data | KP-B05, KP-B06 Rack And Pinion Elevator |
| Max. Lifting Height | 400 m |
| Payload | 2,000 kg |
| Lifting Speed | 0–36 m/min. |
| Cage Size (internal) | 3.2(L)x1.5(W)*2.35(H) meter |
| Motor Control | VFD control |
| Motor Power | 2x11 kw |
| Gearbox | KANGBO make Helical reducer |
| Safety Device Type | centrifugal brake |
| Type of Mast | square column 650*650 mm with bolted rack |
| Length Mast Section | 1.508 m |
| Rack Module | 8 |
