SC200/200 Full Protection 450 Meter 2 Tons Payload Material Lift Elevator
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | Construction site elevator rack pinion type SC200BG KP-B11 SC200-200BG KP-B12 |
| Minimum Order Quantity | 1 set |
| Price | in USD |
| Packaging Details | export package |
| Delivery Time | 25-30 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 300 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Description | Material Lift Elevator | Design | Modular And European Standard |
|---|---|---|---|
| Material | Q355B Steel | Production | Standardized Production, Processed By CNC Machines, Laser, Robots In Assembly Line |
| Feature | Full Protection | Model | SC200/200 |
| Standard | EU Regulations | Finishing | Sand Blasting, Paint, Galvanised |
| Highlight | SC200/200 lift,450m Construction Site Elevator |
||
Product Description
SC200/200 Full Protection 450 Meter Material Lift Elevator
Material Lift Elevator Main Features
1. with the buffer device of the driving mechanism cage top set, the cage running more smoothly;
2. humanized cage design, increase staff comfort;
3. unique structural detail design, proprietary technology;
4. leading production process to ensure that every link of the equipment;
5. industry best matching, reliable quality;
6. precision assembly, transmission precision, smooth;
7. provide professional solutions to special projects;
8.safety devices, reliable control system.
Material Lift Elevator Design
It is the truly modular rack and pinion hoist design, so the elevator drive devices and cars are generic and interchangeable.
Multiple choice of construction lifts car doors or ramps is available.
The modular and standardizing system makes the Kangbo construction elevators be flexible, efficient, safe, productive, low energy consumptive and ownership cost, making them the best choice for both construction and rental companies.
Material Lift Elevator Certificate
TUV proved according to European Regulation EN 12159:2012, EN 60204-1:2006/A1:2009.
Material Lift Elevator Technical Data
| Item & Article No. | SC200BG, KP-B11; SC200/200BG, KP-B12 Material Lift Elevator |
| Payload Capacity | 2,000KG per Cage |
| Lifting speed | 0–60 meter/minute. |
| Max. lifting height | 450 m |
| Cage width (internal) | 1.5 m |
| Cage length (internal) | 3.2 m |
| Cage height (internal) | 2.35 m |
| Motor control | FC control |
| Engine power | 3x15 KW per Cage |
| Gearbox | Helical reducer |
| Safety device type | centrifugal brake |
| Power supply range | 380–500 V, 50 or 60 Hz, 3 phase |
| Type of mast | square column 650*650 mm with bolted rack |
| Length mast section | 1.508 m |
| Rack module | 8 |
