Double Cage 46 M / Min Rack & Pinion Construction Hoist Elevator
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200BZ, KP-B07,B08 |
| Minimum Order Quantity | 1 set |
| Price | Negotiate |
| Packaging Details | export package |
| Delivery Time | 30 days |
| Payment Terms | T/T, L/C |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Item | Construction Hoist Elevator | Material | Steel Plate |
|---|---|---|---|
| Processing Procedure | Cut By Laser, Processed By CNC Machines In Tool Fixtures. | Finishing | Painted And Galvanised |
| Speed | 46 M/Min | Feature | Long Work-Life |
| Highlight | Cage rack & pinion hoist,46m / min Construction Hoist Elevator |
||
Product Description
Long Work-Life Double Cage 46 M/Min. Construction Hoist Elevator
Construction Hoist Elevator Advantages
1. Low operating cost but high efficiency;
2. Simplicity in operation;
3. High degree of safety;
4. Long durability;
5. Low energy consumption.
6. CE, ISO and GOST certificates.
Construction Hoist Elevator Design
It is the truly modular rack and pinion hoist design, so the elevator drive devices and cars are generic and interchangeable.
Production and Materials
KANGBO implements the true modular design of rack and pinion hoists, standardization and fine finishing of lifts parts and spare parts, and assembly line production. The material elevator components are versatile and universal.
Construction Hoist Elevator Features and Advantages
* The material hoist runs without vibration or trembling. The man and material lift starts and stops without surging or jerking.
* The passenger and elevator is reliable with very little breakdown and is durable with very long work-life.
Construction Hoist Elevator Parameters
| Technical Data | KP-B07, B08 Construction Hoist Elevator |
| Payload Capacity | 2,000 kg |
| Lifting Speed | 0–46 m/min. |
| Max. Lifting Height | 450 m |
| Cage Width (internal) | 1.5 m |
| Cage Length (internal) | 3.2 m |
| Cage Height (internal) | 2.35 m |
| Motor Control | Frequency Control |
| Engine Power | 2x15 kw |
| Gearbox | Helical Gearbox of KANGBO Make |
| Safety Device | Centrifugal Brake |
| Power Supply Range | 380–500 V, 50 or 60 Hz, 3 phase |
| Mast Section | Square column 650*650*1508 mm with bolted rack |
| Rack Module | 8 |
