FC Control Motor Construction Site Lift SC200 SC200/200 Max Lifting Height 450M
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200, SC200/200 |
| Minimum Order Quantity | 1 Unit |
| Price | Negotiate |
| Packaging Details | Export package |
| Delivery Time | 30 days afetr receipt of T/T or L/C |
| Payment Terms | L/C, T/T |
| Supply Ability | 150 units per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Q355B Steel Plate | Processing | Cut By Laser, Processed By CNC Machines |
|---|---|---|---|
| Apply Location | Construction Site, Plants, Malls, Etc. | Purpose | Vertical Transportation Of Materials And Persons |
| Finishing | Sand Blasting, Paint Or Galvanised | Description | Construction Site Elevator |
| Highlight | Construction Site Lift SC200,FC Control Motor Construction Site Lift,450M Lifting Height Construction Site Elevator |
||
Product Description
FC Control Motor Construction Site Lift SC200, SC200/200 Max Lifting Height 450M, KP-B05,B06
Product Features
Adopt own-make high efficient helical gearbox.
Types of exit doors are availble, including Flap Door as loading/unloading ramp.
Reliable, very little breakdowns.
Extremely long work life.
Production
Main parts are made of Q355B cool roll steel plate, cut by Laser and processed by CNC machines and robots.
Enlarged and thickened main steel channel of the cage frame.
The edge totally welded cage roof makes the elevator car roof waterproof.
Technical Data
| Artical Number | KP-B05, KP-B06 |
| Payload capacity | 2,000 kg |
| Lifting speed | 0–36 m/min. |
| Max. lifting height | 450 m |
| Cage width (internal) | 1.5 m |
| Cage length (internal) | 3.2 m |
| Cage height (internal) | 2.35 m |
| Motor control | VFC control |
| Engine power | 2x11 kw |
| Gearbox | Helical Type |
| Safety device type | Centrifugal Brake |
| Power supply range | 380–500 V, 50 or 60 Hz, 3 phase |
| Type of mast | Square Column 650*650 mm with bolted Rack |
| Length mast section | 1.508 m |
| Rack modulus | 8 |
